Friday, February 24, 2017

Living the Dream, Day 6 – Blacktail Canyon Serenade

It has been a while, hasn’t it? The last time we were living the dream we had just finished a fine foray to the waterfall at Elves Chasm, near river mile 117 of the Colorado River in Grand Canyon. Since then, I have not tumbled into the whirling waters, nor have I been spinning around in a swirling rapid of monumental magnitude (well, not literally, anyway). But life happens. We get busy and lose track of time. Our mental mojo wanders in another direction. My last post was a video I made about my Thanksgiving with friends. Well…enough of this lollygagging. It’s almost March, for Pete’s sake! Get on with it! It’s time to climb back into the boat, and have a leisurely look around while our boatmen continue to do all the work.

GC Raft Trip 615a
The Great Unconformity near Blacktail Canyon -
click on any pic to enlargenate


We have been floating for several days through the magnificent rocks of the Upper Granite Gorge. For over 40 sinuous river miles, from mile 78 near Mineral Canyon to mile 120 at Blacktail Canyon, the river carves its way through the dense, massive cliffs of Precambrian metamorphic rocks.

Geologic evidence suggests that, around 1.75 billion years ago, a chain of volcanic islands was perched on an unnamed oceanic tectonic plate. Now called the Yavapai Arc and resembling Alaska’s Aleutian Islands, this thousand–mile long chain of islands was slowly on the move. Over millions of years it drifted toward an ancient North American continent, an edge of which stretched from modern–day southern California, up through Utah and Wyoming, and into central Canada. Sandstone, mud, lava, and ash weathered and eroded off the volcanic islands and were deposited and buried in deep ocean basins. For 150 million years, as the island arc glided closer and closer to the ancient continent, these buried sediments were squished, folded, and deformed.

When the Yavapai Arc finally collided with and accreted, or sutured, itself to the continent, it was pushed up and over the edge of our ancient North America, forming a new continental mountain range. The basin deposits were buried even more deeply, up to 10 or 15 miles below the surface. At the pressures and temperatures found at these depths, the sediments metamorphosed into schists, gneisses, and amphibolites. Still they were not deep enough nor hot enough to melt. Deeper in the crust, though, melting did occur due to the higher temperatures and pressures. These melted rocks eventually forced their way up through fractures and fissures into the solid rocks above. It is these dark–colored schists intruded by lighter–colored bands of igneous rocks that so enrapture any geologist (especially this one) who floats this river.

GC Raft Trip 616(a)
Schist happens
The rocks used to be called the Vishnu Schist and Zoroaster Granite. However, after years of more detailed study they now go by a different name – The Grand Canyon Metamorphic Suite. This suite of rocks encompasses the Vishnu Schist (metamorphosed sandstone and shale), Brahma Schist (metamorphosed basalt), and Rama Schist (metamorphosed rhyolite ash). Their average age has been radioactively pegged at between 1.75 to 1.73 billion years.

Dated at 1.84 billion years old, rocks of the Elves Chasm Pluton are the oldest known rocks in the southwest US. They are the basement, or foundation, upon which the rocks of the younger Grand Canyon Metamorphic Suite were deposited. The Elves Chasm Pluton is particularly well exposed between river miles 112 and 118, through which we have just passed.

As we float along the three–mile stretch of Stephen Aisle, the panorama of Precambrian igneous and metamorphic rocks slowly but steadily dips beneath the water. The familiar 540–million–year–old Tapeats Sandstone takes its place at river level, reappearing like a long–lost friend. We soon reach Blacktail Canyon and disembark for lunch.

GC Raft Trip 621a
This is how we do lunch on the river

GC Raft Trip 620a
Small-scale cross-bedding in the Tapeats Sandstone
 After beer and a sandwich, we wander across the sand and enter the narrowing slot of Blacktail Canyon. It’s time for a surprise serenade by one of the guides who has brought along his camp guitar. The others stretch out on the shaded rocks as the melody of a John Prine tune sways softly in the canyon breeze. Meanwhile, I have my own look around at The Great Unconformity, that 1.2 billion year swath of missing geologic time that John Wesley Powell noticed on his first trip down the canyon in 1869.

Because there is a regional westward dip of the rock strata in this vicinity, the Tapeats Sandstone descends to river level. From a slightly northeast direction, Blacktail Canyon drains a notch along the Great Unconformity, exposing the contact between the Tapeats and the underlying Vishnu Schist. There is lots to see here: large quartz boulders and cobbles in the bottom of the otherwise fine–grained sandstone, along with garnets in the schist. The garnets give an indication of the pressures and temperatures that this schist underwent (remember – rocks don’t suffer metamorphism, they enjoy it!) while the cobbles and boulders tell a story of a 540–million–year–old Cambrian Sea advancing across the barren, low–relief landscape, relentlessly breaking and churning the resistant schists into boulders, cobbles, and sand.

GC Raft Trip 625a
Strolling into Blacktail Canyon

GC Raft Trip 626a
The Principle of Inclusions is alive and well!

GC Raft Trip 628a
Towering Tapeats

GC Raft Trip 631a
Garnets with plagioclase rims indicate decompression from depth


GC Raft Trip 634a
Blacktail serenade

GC Raft Trip 639a
Someone is caressing the Great Unconformity
Somewhere in Blacktail Canyon there lurks the contact between the older Elves Chasm Pluton and the younger Vishnu Schist. I do not know if that is what I am looking at. Sadly, there is no one to clarify. I wish I knew where to look, what to look for. On this trip, though, we do not have the time to search it out. This is not a geology trip per se but just a general tour, so I am on my own trying to figure this stuff out. However, I am surely having one helluva good time doing what I can!

GC Raft Trip 641a
Kris enjoying a beautiful day on the river


We wander slowly back to the boats. The sky is clear and the air is warm. It is a fine day to be on the river. Beyond Blacktail Canyon we will be in the Middle Granite Gorge.

GC Raft Trip 644a
Beyond Blacktail Canyon

GC Raft Trip 645a

Somewhere past Conquistador Aisle, past Forster Rapid and Fossil Rapid and 128–Mile Rapid, the sublime palette of dark schists interwoven with pink igneous intrusions appears once again. As with everything in this canyon, the palette mesmerizes the mind.

GC Raft Trip 647a


GC Raft Trip 648a


GC Raft Trip 652a


GC Raft Trip 653a


GC Raft Trip 660a


GC Raft Trip 661a
The canyon widens as we exit the metamorphic rocks

At our campsite near 135–Mile Rapid, the tilted layers of the Grand Canyon Supergroup reappear in the downstream distance. Our tents seem to be tilted almost as much as those layers. I hope I don’t wake up in the river.

GC Raft Trip 663a


GC Raft Trip 664a


GC Raft Trip 666a


******************************************


References:
Abbott, L., and Cook, T., 2004, Hiking the Grand Canyon’s Geology, The Mountaineer Books
Blakey, R. and Ranney, W., 2008, Ancient Landscapes of the Colorado Plateau, Grand Canyon Association
Collier, M., 1980, An Introduction to Grand Canyon Geology, Grand Canyon Natural History Association
Karlstrom, K.E., Ilg, B.R., Williams, M.L., Hawkins, D.P., Bowring, S.A., and Seaman, S.J., 2003, Paleoproterozoic Rocks of the Granite Gorges, in Beus, S. and Morales, M., eds., Grand Canyon Geology, 2nd edition, Oxford University Press
Potochnik, A.R., and Reynolds, S.J., 2003, Side Canyons of the Colorado River in Grand Canyon, in Beus, S. and Morales, M., eds., Grand Canyon Geology, 2nd edition, Oxford University Press
Stevens, L., 2013, The Colorado River in Grand Canyon – River Map & Guide, Grand Canyon Wildlands Council
